Growatt / ED-NV821143

PV Smart Meter GROWATT GROWATT TPM-C, 3-phase, 5A~80A

PV smart meter 5-80A, 3-phase, with RS485, Modbus, 3P4W Features: The smart meter is designed for grid export limitation and self-consumption monitoring. Compatible with Growatt PV inverters. Class1 measurement reliability. With LCD display. Smart Meter is easy to mount on Din rail. Specifications: Rated voltage: AC 230/400V. L-L voltage range: AC 320V ~ 520V. Current: 5A. Current range: 5A ~ 80A. Frequency: 50/60Hz. Number of phases: 3. Accuracy class: class 1 (voltage/current 0.5%, power 1%, frequency 0.2%). Interface: RS485. Baud rate 9600 bit/s. Communication protocol: Modbus RTU. Installation: on DIN rail. Dimensions: 94.5x72x65 mm. Safety class: IP51. Operating temperature: -25°C to 55°C. Operating humidity: Warranty: 24 months. Download Specifications SPM-TPM.pdf

217,80 €

Pieejamība: 3
